About Sangam Ispat

Forging strength. Engineering trust.

Three decades of dimensional discipline, controlled metallurgy, and on-time despatch — quietly powering steel plants, transmission lines, solar farms and infrastructure projects across India.

Established in 1990, Sangam Ispat (India) Pvt. Ltd. is a GeM-registered OEM known for the manufacture of high-quality fasteners, nuts, bolts, and precision-fabricated structures. The unit specializes in module mounting structures for solar applications, supporting India's growing renewable-energy build-out.

Our facility at Plot No.1-B, Sarora, Urla Industrial Area, Raipur runs a complete fastening-solutions stream — from precision-machined hex head bolts and foundation anchor systems to specialty items such as dummy-bar bolts, T-bolts, and rivets for critical applications in steel plants and heavy engineering.

"Built on decades of metallurgical know-how and a culture of dimensional discipline."

Every fastener we ship is the result of carefully controlled raw-material selection, cold/hot forging, thread rolling, and inspection aligned with IS, BS, and ASTM standards. We supply both metric (MM) and imperial (Inch) ranges, with flexibility for custom lengths, grades and finishes as per project drawings.

Quality

Material test certificates on request. Inspection per IS / BS / ASTM.

Innovation

Pre-galvanized solar mounting and project-engineered fastening solutions.

Scale

Cold/hot forging, CNC turning and thread-rolling under one roof in Raipur.

On-time Despatch

Road and rail despatch pan-India. Packing options to suit project logistics.

Product Range — Industrial Fasteners

Every fastener for structural & heavy engineering.

From general-purpose hex bolts to project-specific foundation systems, dummy-bar bolts for continuous casters, and matched nut–washer–stud assemblies — all manufactured to drawing and shipped with full traceability.

Hex Head Bolts — Inch Series

Manufactured across the full range from 5/16" through 1.5" diameter, identified by the traditional Indian trade term 'soot' (1 soot = 1/8 inch). Bolts are produced with hot-forged hex heads and rolled threads for superior fatigue strength.

Length range

From 1" through 18", depending on diameter — extensive coverage for structural and mechanical applications.

Custom lengths

Made to drawing in BSW / UNC thread as specified by the project.

S. No.	Soot (Strands)	Inch Size	Available Lengths (inch)
1	2.5 soot	5/16"	1, 1.25, 1.5, 2, 2.5, 3
2	3 soot	3/8"	1, 1.5, 2, 2.5, 3, 4, 5, 6
3	4 soot	1/2"	1.5, 2, 2.5, 3, 3.5, 4, 5, 6, 7, 8
4	5 soot	5/8"	1.5, 2, 2.5, 3, 3.5, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16
5	6 soot	3/4"	2, 2.5, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16
6	7 soot	7/8"	3, 4, 5, 6, 6.5, 7, 8, 10, 12
7	8 soot	1"	2.5, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16
8	9 soot	1.25"	4, 5, 6, 7, 8, 10, 12, 13, 14, 15, 16
9	10 soot	1.5"	4, 5, 6, 8, 10, 12, 13, 14, 15, 16, 17, 18

Trade Terminology — "Soot"

In Indian fastener trade, diameter is often quoted in soot (sutar) instead of inches, where 1 soot = 1/8 inch. So a 4-soot bolt is 4/8" = 1/2", a 6-soot bolt is 6/8" = 3/4", and a 10-soot bolt is 10/8" = 1.25". This shorthand is still widely used by hardware merchants and fabrication shops across India.

Hex Head Bolts — Metric Series

Our metric hex head bolt range covers diameters from M8 through M36, with one of the most comprehensive length offerings in the region. Manufactured to ISO 4014 / ISO 4017 with metric coarse thread (6g) by default.

Length range

40 mm to 350 mm as standard. Larger lengths and special pitches made to drawing.

Property class

4.6 standard. Higher grades (8.8, 10.9) on request.

S. No.	MM Size	Available Lengths (mm)
1	M8	40, 50, 60, 65, 75
2	M10	40, 50, 65, 75, 80, 100, 125
3	M12	40, 50, 65, 70, 75, 100, 115, 125, 150
4	M16	40, 50, 65, 70, 75, 80, 85, 90, 100, 110, 120, 125, 140, 150, 175, 180, 200
5	M20	40, 50, 65, 70, 75, 80, 85, 90, 100, 110, 120, 125, 140, 150, 175, 180, 200, 210, 220, 225, 250, 275, 300
6	M22	50, 60, 65, 70, 75, 80, 85, 90, 100, 110, 120, 125, 140, 150, 175, 180, 200, 210, 220, 225, 250, 275, 300
7	M24	65, 70, 75, 80, 85, 90, 100, 110, 120, 125, 140, 150, 175, 180, 200
8	M27	75, 80, 85, 90, 100, 110, 120, 125, 140, 150, 175, 180, 200
9	M30	100, 110, 120, 125, 140, 150, 175, 180, 200, 210, 220, 225, 250, 275, 300, 310, 325, 350
10	M36	100, 110, 120, 125, 140, 150, 175, 180, 200, 210, 220, 225, 250, 275, 300, 310, 325, 350

Foundation Bolts

Foundation bolts form the critical interface between structural steel and concrete foundations. Manufactured to project-specific drawings — with options for higher strength grades on request.

Diameter range

16 mm to 64 mm (anchor bolts) — covering main structural columns, transmission towers, solar mounting and heavy machinery.

Length range

1.5 ft to 6 ft — or as per party requirement.

S. No.	Product	Diameter Range	Length Range
1	L Bolt	16 – 40 mm	1.5 ft – 6 ft or per party requirement
2	Anchor Bolt	16 – 64 mm	1.5 ft – 6 ft or per party requirement
3	FD Bolt	16 – 40 mm	1.5 ft – 6 ft or per party requirement

L Bolt

16 – 40 mm dia

Single bend (L-shaped) hooked end embedded in concrete. Suitable for light to medium structural columns, fencing, and equipment baseplates.

Anchor Bolt

16 – 64 mm dia

Heavy-duty bolt with an integral pyramidal base plate at the embedded end and a long threaded projection at the top. Used for main structural columns, transmission towers, heavy machinery, and solar mounting.

FD Bolt

16 – 40 mm dia

Forged bolt with a closed thimble eye at one end for cable/shackle attachment and a threaded shank at the other. Used in transmission-line stay sets, telecom guy-wire assemblies, and suspension hardware.

General Industrial Items

Our specialty range covers fasteners used across steel plants, infrastructure projects, and structural assemblies. Made to order in high-tensile (HT) and mild-steel grades, with options for custom lengths.

Application insight

Dummy bar bolts are essential in continuous casting machines (CCM) of steel plants. T-bolts and square head bolts are commonly used in rail, crane, and heavy machinery assemblies.

Surface finishes

Black / red oxide, hot-dip galvanizing (HDG), zinc plating — as required.

S. No.	Product	Diameter / Width	Length Range	Remarks
1	Dummy Bar Bolt	30 mm, 36 mm	150, 175, 200 mm	H.T. only
2	Pin	16 – 30 mm	100 – 260 mm	Made to order
3	Rivet (Head)	10, 12, 14, 16, 18, 20, 22, 24, 27 mm	Dia 10–12 mm: 50–100 mm \| Dia 14–27 mm: 100–300 mm	—
4	T Bolt / Capsule Bolt	1", 1.25", 1.5"	10 – 18 inch	—
5	Square Head Bolt	16 – 40 mm	Dia 16–22 mm: 70–150 mm \| Dia 24–40 mm: 100–400 mm	—

Nut, Washer & Stud

Companion components for every bolted joint — supplied in matching grades and sizes to complement our bolt range. Both metric and inch series, with full traceability of material grade and dimensional conformity.

Studs

Fully threaded and double-end studs for flange, pipe and pressure-vessel applications. Custom length to drawing.

Washers

Plain washers in mild steel, supplied in standard thicknesses to distribute clamping load and protect mating surfaces.

S. No.	Product	Diameter Sizes (MM)	Diameter Sizes (Inch)	Remarks
1	Nut	8, 10, 12, 16, 20, 22, 24, 27, 30, 36	5/16, 3/8, 1/2, 5/8, 3/4, 7/8, 1, 1.25, 1.5, 2, 2.5, 3	—
2	Washer	8, 10, 12, 16, 20, 22, 24, 27, 30, 36	5/16, 3/8, 1/2, 5/8, 3/4, 7/8, 1, 1.25, 1.5	—
3	Stud	12, 16, 20, 22, 24, 27, 30, 36, 40	5/16, 3/8, 1/2, 5/8, 3/4, 7/8, 1	Length as per party requirement

Solar Mounting Structure Division

Empowering the solar revolution.

High-precision pre-galvanized mounting solutions engineered for India's rooftop, ground-mount and carport solar installations. Built for structural stability, optimized steel usage, and long service life under Indian environmental conditions.

Sangam Ispat pre-galvanized solar mounting structure installed on a rooftop

Pre-galvanized. Project-engineered.

We don't just manufacture steel — we build the infrastructure for a sustainable world. Based in Raipur's industrial hub, we specialize in high-durability solar mounting structures engineered to withstand the test of time and nature.

Every structure reflects a commitment to quality, engineering integrity, and sustainable infrastructure development — backed by our in-house fastener manufacturing, so the entire bolted assembly comes from one supplier.

3 kW System Rooftop — 6 panels

Pre-Galvanized

Total weight 74 kg

Front legs (×2) 3 ft / 80×40×15 mm C

Rear legs (×2) 5 ft / 80×40×15 mm C

Rafters (×2) 13 ft / 80×40×15 mm C

Purlins (×4) 12.5 ft / 41×41 mm Strut

Fasteners M12×40, 12 pcs, GI/SS

Base plate 150×150×6 mm welded

Advantages

Modular & robust design for 10+ years
Easy on-site assembly with minimal tools
Optimized for weight and strength
Compatible with various panel sizes

5 kW System Rooftop — 9 panels

Pre-Galvanized

Total weight 115 kg

Front legs (×3) 3 ft / 80×40×15 mm C

Rear legs (×3) 5 ft / 80×40×15 mm C

Rafters (×3) 13 ft / 80×40×15 mm C

Purlins (×4) 20 ft / 41×41 mm Strut

Fasteners M12×40, 18 pcs, GI/SS

Base plate 150×150×6 mm welded

Advantages

Modular & robust design for 10+ years
Easy on-site assembly with minimal tools
Optimized for weight and strength
Compatible with various panel sizes

Rooftop Structures

Residential and commercial rooftops, pre-galvanized for long service life.

Ground-Mounted

Solar farms, utility-scale ground-mount module mounting structures.

Carports & Canopies

Dual-purpose shade and generation for parking lots and open yards.

SPV Water Pumping

Agricultural and potable water-pumping module mounting structures.

Standards & Quality

Traceable from raw material to despatch.

Every product is manufactured to recognised national and international standards. Mill test certificates are provided on request. Below is a summary of typical grades, standards and finishes available across our product range.

Material Grades MS, IS 2062 · Property Class 4.6 (higher grades on request)

Dimensional Standards IS 1363, IS 1364, IS 1367, ISO 4014, ISO 4017

Thread Standards Metric: ISO Metric Coarse (6g) · Inch: BSW / UNC as specified

Manufacturing Process Cold / hot forging · CNC turning · Thread rolling · Annealed where applicable

Surface Finishes Black oxide (self) · Zinc plated (white / yellow) · Hot-Dip Galvanized (HDG) · Phosphated · Painted

Inspection & Testing Dimensional check · Hardness (Rockwell) · Tensile · Proof load — as per applicable standard

Raw Material Hot-rolled steel rounds & cold-headed wire conforming to IS 1148, IS 2062 equivalents

Packaging HDPE / poly-lined gunny bags · or as per customer specification

Full Range

5/16" to 3" & M8 to M64

Custom Lengths

Made to drawing

Certified Material

Mill TC on request

On-time Despatch

From Raipur, CG
